Shaper Origin Gen2

Upgrades from Gen1 include:

25% larger screen with 2.4x the resolution
Improved scanning performance
Aluminum unibody
Manufactured by Festool in Germany

Shaper Origin is the world’s first handheld CNC machine. Designed with woodworking professionals in mind, Origin brings CNC-level precision to a hand tool, for an ideal blend of human and machine. The magic of Origin is that it is designed to accommodate itself to your workflow - however you work. Use it to dash off a prototype in the shop, making adjustments on the fly. Bring it to a job site to work on an installation when there is no margin for error. Design an entire project from front to back using the intuitive on-tool CAD. Shaper is building the future of power tools. Origin combines precision with repeatability to make hinge and hardware installation simple. Work quickly and confidently in the shop or onsite.

Upgrade your Origin router by purchasing AutoPass (configures your cut depth for multiple passes).

Includes

Shaper Origin with Shaper SM-1 Spindle, router spindle developed in conjunction with Festool
Two 150' rolls of ShaperTape
1/4" upcut spiral cutter
1/8" upcut spiral cutter
60° engraving cutter
1/4" collet
USB flash drive
Tool change accessories
Universal dust collection adapter
In Systainer SysGen3
One-year warranty (extended by an extra year when YOU register your tool)
Email support

ADD BENCHPILOT / PLATE / WORKSTATION

BenchPilot turn Origin into a hands-free milling machine, capable of vertical or horizontal cutting. Let BenchPilot drive Origin so you can focus on other tasks at hand. Simply unclip Origin to use without BenchPilot when needed. Click for more details on BenchPilot.
Plate is a universal template designed to install a wide range of hardware, inlay bow ties, round corners, route system 32 holes and so much more. Plate makes it easy to say goodbye to drawers full of hardware templates you may have lying around. Click for more details on Plate.
Workstation is the ultimate workspace and fixturing solution for your benchtop cutting operations. It’s designed to streamline and expand upon Origin’s abilities, offering rapid, repeatable and precise fixturing of a wide range of stock configurations. Click for more details on Workstation.
Add in pull-down menu above to save $75 on each (BenchPilot/Plate/Workstation) when purchasing along with Origin. Save an additional $100 on Shelf Upgrade Kit when purchasing with Origin, BenchPilot, and Workstation.

Specifications

Input power: 120VAC, 60 Hz. 7A
Spindle motor: 720W brushed AC motor. 10,000 - 26,000 RPM with load compensating speed control. Soft-start, over-temperature and over-load safety cut-offs. Produced by Festool to Shaper specifications.
Collet: 1/4"
Depth control: 43mm (1.7") of total Z-axis travel. Digitally adjustable depth-of-cut. Automated touch-off sensor.
Dust extraction port: 34mm inner diameter by 39mm outer diameter. Fits 27mm & 36mm Festool suction hoses. Designed with the SM-1 spindle in mind to provide optimal debris extraction.
Dust collection adapter: 2-1/4" outside diameter nozzle for use with US-standard wet/dry vacs. Length of 6.5'.
Connectivity: Wi-fi enabled for transfer of design files from ShaperHub™ and for receiving software updates. USB port for offline transfer of design files.
Digital Cut Files: Works with standard vector files (.SVG). Includes on-tool design capabilities.
Touch screen: Capacitive multi-touch full-color LCD
Origin dimensions: 13.35" (handle-to-handle) x 8.94" x 12.04"
Systainer dimensions: 15-1/2" x 11-1/2" x 17" (SysGen3)
Origin weight: 14.9 pounds

Shaper Origin

Shaper SO2-UN Origin Handheld CNC Router
